| Product name | Self-priming sewage pump |
|---|---|
| Fiow rate(m³/h) | 50-800m³/h |
| Lift (m) | 10-100m |
| Speed(rpm) | 1500/3000 |
| Frequency(hz) | 50/60 |
| Generator Type | Silent, Trailer, Open Frame |
| Starting system | 24V DC Electric Start |
| Cooling System Type | Water cooling system |
| Can be customized | Support customization |
About Water Pump Generator Set:
Automotive Industry, Biofuel Industry, Commercial Buildings, Developing World Water Solutions, District Energy, Drinking water treatment, Family Homes, Food and Beverage Industry, HVAC OEM, Industrial Boilers, Industrial Utilities, Irrigation and Agriculture, Pharmaceutical industry, Washing and Cleaning, temperature control, Wastewater Transport and Flood Control, wastewater treatment, Water Treatment Solutions
| Model | Flow | Max. lift | Power | Speed | Efficiency | Self-priming height | Weight |
| YT40-25 | 40m³/h | 25m | 7.5KW | 1450r/min | 50% | 5.5m | 200KG |
| YT65-25 | 65m³/h | 25m | 7.5KW | 2900r/min | 52% | 5.5m | 240KG |
| YT40-16 | 40m³/h | 16m | 4KW | 1450r/min | 50% | 5.0m | 240KG |
| YT40-25 | 40m³/h | 25m | 7.5KW | 1450r/min | 50% | 5.5m | 200KG |
| YT25-40 | 25m³/h | 40m | 7.5KW | 2900r/min | 50% | 5.5m | 200KG |
| YT65-25 | 65m³/h | 25m | 5.5KW | 2900r/min | 52% | 5.5m | 240KG |
| YT80-35 | 80m³/h | 35m | 15KW | 2900r/min | 45% | 5.5m | 285KG |
-High-Quality Diesel Water Pump: Supply 3-Inch Diesel Water Pump Set is a reliable choice for farming applications, ensuring efficient water pumping operations.
-Durable Construction: The trailer-type, open frame design provides excellent durability and mobility for easy transportation and installation, as requested by our valued customer.
-Low Noise Operation: This silent-type diesel water pump operates at a speed of 3000rpm, minimizing noise pollution and disturbance in the farming environment.
-Wide Frequency Compatibility: The pump is compatible with both 50Hz and 60Hz frequencies, making it suitable for various regional power grid systems, as –specified by our customer.
-Comprehensive Warranty: The product comes with a 3-month to 1-year warranty, providing peace of mind for our customers and ensuring long-term reliability of the pump.
Quick Connector
Quick connector for easier and more convenient pipeline connection.
Control System
Diesel engine water pump controller, electromagnet start outdoor waterproof box
Mobile and convenient
Inflatable solid tires, shock springs, hubs, axles, trailer bars, lift adjustment feet
Easy to maintain
A detachable sewage cleaning port makes cleaning and maintenance easier
Multi-purpose solution:
• Fresh water, river water, rainwater
• Slurry & semi-solid material
• Well pointing – high vacuum pump capacity
• Fire fighting or building a high-pressure pump station
• 24-hour reliability
• Designed for high ambient environments
Standard equipment:
•Diesel engine assembly
•Water pump assembly
•The flexible shaft coupling unit
•Steel mounting skid
Optional equipment:
•Built-in fuel tank (Additional separate fuel tank is available.)
•Clutch or gearbox
•Battery
•Engine and water pump protection system
•Automatic start and self-shut-off function(ATS AMF)
•Remote control/off-duty control/PC control or mobile phone control
•Trailer and weather canopy
•Suction hose, delivery hose or lay flat hose, PP/PE pipe, wire reinforced PVC, or rubber hose.
•Foot valve, gate valve, non-return valve, butterfly valve, pipe fittings, and hose clamps
•Engine and water pump additional spare parts relatively.
